Answer
Sep 20, 2024 - 07:08 AM
If you have any quest you can reach us at: Contact Us (arblueclean.com)
Installation Instructions for Wall Mount
-
Watch the Installation Video: You can find the installation video for the wall mount here.
(20+) Facebook -
Wall Mount Dimensions:
- Width: 17.75" inches
- Height: 16" inches
-
Pressure Washer Dimensions:
- Length: Approximately 24 inches (extends about 6 inches beyond the mount)
- Metal Handles Depth: Around 7 inches
- Height: Around 13 inches
-
Hose Holder: The hose holder has a small footprint, which may vary depending on how you hang your hose.
-
Mounting Recommendations:
- Direct to Studs: The wall mount is perfectly spaced for studs that are 16 inches on center.
- Studs Spacing: If your studs are 24 inches on center, use a piece of plywood that spans the distance between the studs for proper securement. Then, attach the wall mount to the plywood.
- Avoid Particle Board or MDF: Do not use particle board or MDF as a backer. Use solid wood, or frame a backer with Plywood.
